Product is suitable for:
               Mainly applicable to a variety of non-metallic materials tensile, peel, tear, compression, bending, shear test



Series XT
Model 100,200,500,1000,2000,5000,10000,20000,30000
Maximum load of 100N, 200N, 500N, 1000N, 2000N, 5000N, 10000N, 20000N, 30000N
Accuracy class 1 / 0.5
0.2% to 100% / 0.4% to 100% of the effective measuring range
Indication of force measurement accuracy within ± 1% / ± 0.5% of indication
1 / ± 250000 Ma, the maximum resolution of the testing machine load inside and outside, regardless of the file, and the full resolution unchanged
The load sensor basic configuration: pull, pressure sensor (maximum load) a
Extended configuration: can be equipped with multiple sensors
Effective test width 370mm (widening) according to customer requirements.
Effective tensile space 750mm (according to customer requirements heightening)
Test speed range of 0.001 ~ 500mm/min
Displacement measurement the accuracy indication within ± 0.5% / indication within ± 0.2%
Deformation measurement system standard configuration: large deformation: minimum gauge 10mm deformation range: 800mm
Extensions Configuration: small deformation: gauge 25mm, 50mm, 100mm deformation range: 5mm, 10mm, 25mm
Deformation measurement the accuracy indication within ± 0.5% (according to customer requirements optional large deformation or small deformation)
The test station safety device electronic limit protection
Test bench lifting device fast / slow two-speed automatic control, can jog
The test station return function manually or automatically two options after the end of the trial to return to the initial position at top speed automatic or manual
Overload protection to more than 10% of the maximum load, the machine automatically to protect
Fixture configuration tensile fixture a
Host size 640 × 430 × 1550mm
Motor 220V ± 10% 0.4KW
Host weight (approximately) 150 Kg
